ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 943
<Ch>
Channel number
<Seg>
Sweep segment number. This suffix is ignored; the setting controls the whole
segmented sweep.
<Boolean>
ON: Use independent bandwidth settings, to be defined via
[SENSe<Ch>:]SEGMent<Seg>:BWIDth[:RESolution].
OFF: Reset the bandwidth in all sweep segments to the bandwidth for unsegmented
sweeps, defined via SENSe<Ch>:BWIDth[:RESolution]. ON will not restore the
previous values.
*RST value
OFF. The parameter is automatically switched to ON when a bandwidth is entered
using [SENSe<Ch>:]SEGMent<Seg>:BWIDth[:RESolution].
SCPI,
Command
Types
Device-specific, command or query
Example:
SEGM:ADD
Create a new sweep segment no. 1 in channel no. 1 using default settings and thus
10 kHz measurement bandwidth.
SEGM:BWID 1 MHZ
Increase the resolution bandwidth to 1 MHz.
SEGM:BWID:CONT OFF
Couple the bandwidths in all segments and reset the bandwidth in segment no. 1 to
the initial value.
[SENSe<Ch>:]SEGMent<Seg>:BWIDth[:RESolution]:SELect NORMal | HIGH
Defines the Selectivity in sweep segment no. <Seg>. At the same time, the command activates separate
selectivity setting in all sweep segments
([SENSe<Ch>:]SEGMent<Seg>:BWIDth[:RESolution]SELect:CONTrol ON).
<Ch>
Channel number
<Seg>
Sweep segment number
NORMal
Use IF filter with normal selectivity and short settling time.
HIGH
Use IF filter with higher selectivity but larger settling time.
*RST value
NORMal
SCPI, Command
Types
Device-specific, command or query
Example:
SEGM:ADD
Create a new sweep segment no. 1 in channel no. 1 using default settings
and thus NORMal selectivity.
SEGM:BWID:SEL HIGH
Activate an IF filter with high selectivity.
