R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 942
Use [SENSe<Ch>:]SEGMent<Seg>:INSert to create a segment with specific channel settings.
<Ch>
Channel number If unspecified the numeric suffix is set to 1.
<Seg>
Sweep segment number. Segment numbers must be sequential. If n segments
already exist, the added segment must have the segment number n+1.
*RST value
–
SCPI, Command
Types
Device-specific, no query.
Example:
SEGM:INS 1MHZ, 1.5MHZ, 111, -21DBM, 0.5S, 0, 10KHZ
Create a sweep segment with a sweep range between 1.0 MHz and 1.5 MHz.
SEGM2:ADD
Create a second sweep segment. The frequency range of the second segment
will be between 1.5 MHz and the maximum frequency of the analyzer.
[SENSe<Ch>:]SEGMent<Seg>:BWIDth[:RESolution] <Bandwidth>
Defines the resolution bandwidth of the analyzer (Meas. Bandwidth) in sweep segment no. <Seg>. At the
same time, the command activates separate bandwidth setting in all sweep segments
([SENSe<Ch>:]SEGMent<Seg>:BWIDth[:RESolution]:CONTrol ON).
<Ch>
Channel number
<Seg>
Sweep segment number
<Bandwidth>
Resolution bandwidth.
Range [def. unit]
1.0E-6 Hz to 5 MHz [Hz]. UP and DOWN increment/decrement the bandwidth in
1-2-5 steps for each decade. The analyzer rounds up any entered value between
these steps and rounds down values exceeding the maximum bandwidth.
*RST value
10 kHz
SCPI,
Command
Types
Device-specific, command or query
Example:
SEGM:ADD
Create a new sweep segment no. 1 in channel no. 1 using default settings and
thus 10 kHz measurement bandwidth.
SEGM:BWID 1 MHZ
Increase the resolution bandwidth to 1 MHz.
[SENSe<Ch>:]SEGMent<Seg>:BWIDth[:RESolution]:CONTrol <Boolean>
Selects common or independent Meas. Bandwidth settings for the sweep segments.
