minus the minimum frequency span ([SENSe<Ch>:]SEGMent<Seg>:FREQuency:SPAN).
[SENSe<Ch>:]SEGMent<Seg>:INSert
<Start>,<Stop>,<Points>,<Power>,<Time>|<Point Delay>,<Unused>,<Meas.
Bandwidth>[,<LO>,<Selectivity>]
Adds a new sweep segment with specific channel settings.
Entry of the first seven numeric parameters is mandatory; no default values are provided. All settings can
be changed for existing segments using other commands of the [SENSe<Ch>:]SEGMent<Seg>...
subsystem.
Note: Use [SENSe<Ch>:]SEGMent<Seg>:Add to create a segment with default channel settings. Use
[SENSe<Ch>:]SEGMent<Seg>:DEFine to change or query all settings of an existing segment.
<Ch>
Channel number
<Seg>
Sweep segment number. Segment numbers must be sequential. The specified
segment number must be smaller or equal to the number of existing segments plus
1. Moreover, segment numbers must selected such that the corresponding
frequency ranges are in ascending order.
If one or more sweep segments with segment numbers <Seg> or larger exist in the
current channel, then all these existing segment numbers are incremented by 1 and
the new segment is inserted as segment no. <Seg>.
<Start>,
<Stop>
Start and stop frequency of the segment. See
[SENSe<Ch>:]SEGMent<Seg>:FREQuency:STARt and
[SENSe<Ch>:]SEGMent<Seg>:FREQuency:STOP.
Range [def.
unit]
Depending on the analyzer model. [Hz]
<Points>
Number of sweep points in the segment. See
[SENSe<Ch>:]SEGMent<Seg>:SWEep:POINts.
Range [def.
unit]
1 to 60001. [1] 1 is allowed if start and stop frequencies are equal.
<Power>
Internal source power in the segment. See
[SENSe<Ch>:]SEGMent<Seg>:POWer.
Range [def.
unit]
–40 dBm to +10 dBm. The exact range depends on the analyzer model; refer to the
data sheet [dBm]. UP and DOWN increment/decrement the source power in 1-dB
steps.
<Time>
Duration of the sweep in the segment. See
[SENSe<Ch>:]SEGMent<Seg>:SWEep:TIME. In the setting
[SENSe<Ch>:]SEGMent<Seg>:INSert:SELect DWELl, this parameter is
replaced by <Point Delay>. AUTO activates automatic sweep time setting in the
segment, which is equivalent to the minimum sweep time possible.
Range [def.
unit]
Depending on other channel settings [s].
<Point
Delay>
Delay for each partial measurement in the segment. See
[SENSe<Ch>:]SEGMent<Seg>:SWEep:DWELl. In the setting
[SENSe<Ch>:]SEGMent<Seg>:INSert:SELect SWTime, this parameter is
replaced by <Time>.
Range [def.
unit]
0 s to 2.5E+003 s. [s] AUTO activates automatic sweep time setting in the segment,
which is equivalent to a meas. delay of 0 s.
Ignored parameter, should be set to the default value 0.
