[SENSe<Ch>:]SEGMent<Seg>:FREQuency:STOP.
[SENSe<Ch>:]SEGMent<Seg>:FREQuency:STARt <Start>
Defines the Start frequency of sweep segment no. <Seg>.
<Ch>
Channel number
<Seg>
Sweep segment number
<Start>
Start frequency of the sweep.
Range [def. unit]
Depending on the instrument model [Hz]. The increment is 0.1 kHz.
*RST value
– (no sweep segment defined after reset)
SCPI, Command
Types
Device-specific, command or query
Example:
SEGM:INS 1MHZ, 1.5MHZ, 111, -21DBM, 0.5S, 0, 10KHZ
Create a sweep segment with a sweep range between 1.0 MHz and 1.5
MHz.
SEGM:FREQ:STAR?
Query the start frequency of the created segment. The response is
1.0000000000E+006.
Note: If the start frequency entered is greater than the current stop frequency
([SENSe<Ch>:]SEGMent<Seg>:FREQuency:STOP), the stop frequency is set to the start frequency plus
the minimum frequency span of 1 Hz.
[SENSe<Ch>:]SEGMent<Seg>:FREQuency:STOP <Stop>
Defines the Stop frequency of sweep segment no. <Seg>.
<Ch>
Channel number
<Seg>
Sweep segment number
<Stop>
Stop frequency of the sweep.
Range [def. unit]
Depending on the instrument model [Hz]. The increment is 0.1 kHz.
*RST value
– (no sweep segment defined after reset)
SCPI, Command
Types
Device-specific, command or query
Example:
SEGM:INS 1MHZ, 1.5MHZ, 111, -21DBM, 0.5S, 0, 10KHZ
Create a sweep segment with a sweep range between 1.0 MHz and 1.5
MHz.
SEGM:FREQ:STOP?
Query the stop frequency of the created segment. The response is
1.5000000000E+006.
Note: If the stop frequency entered is smaller than the current start frequency
([SENSe<Ch>:]SEGMent<Seg>:FREQuency:STARt), the start frequency is set to the stop frequency
