R&S ZVB - Page 966

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 951
<Unused>
<Meas.
Bandwidth>
Resolution bandwidth in the segment. See
[SENSe<Ch>:]SEGMent<Seg>:BWIDth[:RESolution].
Range [def.
unit]
1.0E-6 Hz to 5 MHz [Hz].
<LO>
Position of the local oscillator frequency LO relative to the RF frequency (Spur
Avoid). See [SENSe<Ch>:]SEGMent<Seg>:SBANd.
Range [def.
unit]
POSitive: LO > RF
NEGative: LO < RF
AUTO: The analyzer auto-selects the local oscillator frequency, depending on the
receiver (RF) frequency and the test port.
<Selectivity>
Selectivity of the IF filter. See
[SENSe<Ch>:]SEGMent<Seg>:BWIDth[:RESolution]:SELect.
Range [def.
unit]
NORMal | HIGH [–]
SCPI,
Command
Types
Device-specific, no query.
Example:
SEGM:INS 1MHZ, 1.5MHZ, 111, -21DBM, 0.5S, 0, 10KHZ
Create a sweep segment with a sweep range between 1.0 MHz and 1.5 MHz.
SEGM2:ADD
Create a second sweep segment. The frequency range of the second segment will
be between 1.5 MHz and the maximum frequency of the analyzer.
[SENSe<Ch>:]SEGMent<Seg>:INSert:SELect SWTime | DWELl
Defines whether the sweep time of a new segment, i.e. numeric parameter no. 5 of the command
[SENSe<Ch>:]SEGMent<Seg>:INSert, is entered as a segment sweep time or as a meas. delay.
<Ch>
Channel number
<Seg>
Sweep segment number
SWTime
Use segment sweep time.
DWELl
Use meas delay.
*RST value
SWTime
SCPI, Command
Types
Device-specific, command or query
Example:
SEGM:INS:SEL DWEL
Select the meas. delay to determine the sweep time in a new sweep segment.
SEGM:INS 1MHZ, 1.5MHZ, 111, -21DBM, 0.01S, 0, 10KHZ
Create a sweep segment with a sweep range between 1.0 MHz and 1.5 MHz
and a meas. delay of 10 ms.
SEGM:SWE:TIME?
