COLOR ADJUSTMENT 26 July 2002
3-64
Printer Mode
There are five adjustable modes selected by printer SP1-102:
• 1800 x 1200 photo mode
• 1800 x 600 text mode
• 1800 x 600 graph mode
• 600 x 600 photo mode
• 600 x 600 text mode
K C M Y
Highlight
Middle
Shadow
IDmax
SP1-104-1
SP1-104-2
SP1-104-3
SP1-104-4
SP1-104-21
SP1-104-22
SP1-104-23
SP1-104-24
SP1-104-41
SP1-104-42
SP1-104-43
SP1-104-44
SP1-104-61
SP1-104-62
SP1-104-63
SP1-104-64
Adjustment Procedure
1. Do ACC for the printer mode.
2. Turn the main power off and on.
3. Enter SP mode.
4. Select “Printer SP”.
5. Select SP1-102 and select the print mode that you are going to adjust.
6. To review the image quality for these settings, choose SP1-103-1 to print out a
tone control test sheet.
7. Adjust the color density with SP1-104 as shown below comparing the tone
control test sheet with the C4 test chart.
NOTE: Adjust the density in order from “ID Max”, “Shadow”, “Middle”, and then
“Highlight”.
8. Save the adjusted settings with SP1-105.
To Next Page
