SP5-804
-XXX
Description
53 Fuser Main Relay Fusing Main Relay
54 Fusing Bias Fusing Bias
55 Scanner Lamp
100 Bank Upper Feed 1st paper feed clutch (optional paper tray unit)
101 Bank Lower Feed 2nd paper feed clutch (optional paper tray unit)
102 Bank Feed Motor: L 1st paper feed motor (optional paper tray unit)
103 Bank Feed Motor: H 1st Paper feed motor – half speed (optional paper tray
unit)
110 Shift Tray Motor: CW Shift Tray Motor – continuous clockwise
111 Shift Tray Motor: CCW Shift Tray Motor – continuous counter-clockwise
112 Shift Tray Motor: Run Shift Tray Motor – shifts once
120 Duplex Reverse Motor
(Forward)
Duplex: Inverter motor
121 Duplex Reverse Motor
(Reverse)
Duplex: Inverter motor – reverse
122 Duplex Feed Motor
(Forward)
Duplex: Transport motor
123 Duplex Feed Motor
(Reverse)
Duplex: Transport motor – reverse
124 Duplex Solenoid Duplex: Inverter gate solenoid
125 Duplex Free Run Duplex: Free run
130 Bridge Motor: H
131 Bridge Motor: L
132 Bridge Gate Sol
140 Fusing Fan: H
141 Fusing Fan: L
142 Dev Fan: H Development Fan Motor: H
143 Dev. Fan: L Development Fan Motor: L
144 Cooling Fan: H Controller Fan Motor: H
145 Cooling Fan: L Controller Fan Motor: L
146 Ozone Fan: Hi
147 Ozone Fan: Low
160 Bridge Cooling Fan: H
161 Bridge Cooling Fan: L
162 PSU Fan
170 Forced Lubricant The following parts are switched on.
O/B cleaning contact clutch
T/B cleaning solenoid
T/B cleaning contact clutch
