LASER EXPOSURE 26 July 2002
6-42
6.8 LASER EXPOSURE
6.8.1 OVERVIEW
1. LD Unit
2. Synchronization Detector
3. Synchronization Detector Mirror
4. Dust Shield Glass
5. 3rd Mirror
6. Polygon Mirror Motor Unit
7. W-Toroidal lens (WTL)
8. Fθ Lens
9. 1st Mirror
10. 2nd Mirror
11. Cylindrical Lens
B051D202.WMF
1
2
3
5
7
8
6
9
11
10
4
