26 July 2002 DUMMY
5-71
Service
Tables
SP5-804
-XXX
Description
10 Transfer Motor: Low
Speed
Main motor: 89 mm/s
11 Regist Clutch Registration clutch
12 Interchange Upper
Gate
Interchange Junction Gate Solenoid 1
13 Interchange Lower
Gate
Interchange Junction Gate Solenoid 2
14 By-pass Feed Clutch By-pass paper feed clutch
15 By-pass Pick-Up
Solenoid
By-pass pick-up solenoid
16 Development Clutch: M Development clutch: M
17 Development Clutch: C Development clutch: C
18 Development Clutch: Y Development clutch: Y
19 Development Clutch: K Development clutch: K
20 Development Motor
(Forward)
Development motor
21 Development Motor
Half Speed (Forward)
Development motor: Half Speed
22 Development Motor
(Reverse)
Development motor: Reverse
23 Development Motor
Half Speed (Reverse)
Development motor: Reverse Half Speed
24 Lubricant Clutch OPC belt cleaning clutch
25 Main Motor (Forward) Main motor: Regular Speed
26 Main Motor Half Speed
(Forward)
Main motor: Half Speed
27 Main Motor (Reverse) Main motor: Reverse
28 Main Motor Half Speed
(Reverse)
Main motor: Reverse Half Speed
29 Polygon Motor Polygon motor
30 LD On LD
31 Polygon Motor + LD Polygon Motor + LD
32 Transfer 2nd Solenoid Paper Transfer Solenoid
33 T/B Cleaning Clutch Image transfer belt cleaning clutch
34 T/B Cleaning Solenoid Image transfer belt cleaning contact solenoid
40 Engine Ready Signal Engine Ready Signal
41 ID sensor LED
42 QL
43 Toner End Led Toner End LED
44 Charger Bias Charge corona unit output
45 Development Bias 1 Development Bias: 1
46 Development Bias 2 Development Bias: 2
47 Belt Transfer Image transfer power supply
48 Paper Transfer: + Paper transfer bias: +
49 Paper Transfer: – Paper transfer bias: –
50 T/B Cleaning: + Image transfer belt cleaning bias: +
51 Discharge: H Discharge plate power supply: H
52 Discharge: L Discharge plate power supply: L
