26 July 2002 OVERVIEW
6-1
Detailed
Descriptions
6. DETAILED SECTION DESCRIPTIONS
6.1 OVERVIEW
6.1.1 MECHANICAL COMPONENTS
1. Scanner HP sensor
2. ADF exposure glass
3. Exposure glass
4. 2nd carriage
5. Scanner lamp
6. 1st carriage
7. Original width sensor
8. Scanner motor
9. Sensor board unit
10. Original length sensors
11. Fusing unit
12. Paper transfer roller unit
13. Image transfer belt waste toner bottle
14. Image transfer belt unit
15. OPC belt cleaning unit
16. OPC belt waste toner bottle
17. Paper tray 2
18. Paper tray 1
19. Laser optics unit
20. Development unit
21. OPC belt unit
22. Image transfer belt cleaning unit
B051D107.WMF
10
11
12
13
14
15
16
17
18
19
20
21
22
1
2
3
4
5
6 7
8
9
