ARDF Output Check (SP6-008)
1. Open SP6-008.
2. Select the SP number that corresponds to the component you wish to check.
(Refer to the table below.)
3. Touch ON to test the selected item. To end the test, touch OFF. You cannot
exit and close this display until you touch OFF to switch off the output check
currently executing.
No. Description
1 Feed Motor (Forward)
2 Feed Motor (Reverse)
3 Transport Motor (Forward)
4 Feed Clutch
5 Pick-up Solenoid
6 Junction Gate Solenoid
7 Stamp Solenoid
Finisher Output Check (SP6-118)
1. Open SP6-118.
2. Select the SP number that corresponds to the component you wish to check.
(Refer to the table below.)
3. Touch ON to test the selected item. To end the test, touch OFF. You cannot
exit and close this display until you touch OFF to switch off the output check
currently executing.
Description Description
No.
1000-sheet finisher
No.
500-sheet finisher
1 Fin All Off 101 500 Fin All Off
2 Upper Transfer Motor 102 500 Fin Main Motor
3 Lower Transfer Motor 103 500 Fin Jogger Motor
4 Exit Motor 104 500 Fin Paddle Sol
5 Tray Gate Sol 105 500 Fin Gear Sol
6 Tray Lift Motor 106 500 Fin Lever Sol
7 Jogger Motor 107 500 Fin Tray Motor
12 Stapler Motor 108 500 Fin Stapler Motor
13 Staple Hummer 109 500 Fin Free Run 1
15 Stapler Gate Sol 110 500 Fin Free Run 2
16 Pos. Roller Sol
18 Feed-out Motor
19 Shift Motor
22 Guide Plate Motor
23 Fin Free Run 1
24 Fin Free Run 2
