OVERVIEW 26 July 2002
6-6
Image Transfer
1. Charge corona wire cleaner motor
2. Quenching lamp
3. ID sensor
4. Belt mark sensor
5. T/B waste toner bottle switch
6. T/B waste toner sensor
7. O/B waste toner sensor
8. O/B waste toner bottle switch
9. Pressure roller thermofuse
10. Pressure roller thermistor
11. Heating roller thermistor
12. Pressure roller fusing lamp
13. Heating roller fusing lamp
14. Oil overflow sensor
15. Heating roller thermostat
16. Oil end sensor
T/B: Image transfer belt
O/B: OPC belt
B051D103.WMF
1
2
3
4
5
6
7
8
9
10
11
12
13
15
16
14
