DEVELOPMENT
26 July 2002
6-46
6.9 DEVELOPMENT
6.9.1 OVERVIEW
K
: black,
Y
: yellow
,
C
: cyan,
M
: magenta
1. Memory
chip
2. Toner
cartridge
3. Toner
cartr
idge
agitator
s
4. Dev
elopment
agitat
or
5. Dev
elopment
unit
6.
Toner supply
roller
7. Developm
ent
ro
ller
8. Doctor
ro
ller
9. OPC
belt
☛
!
: Devel
opment – Mono-
component
Developmen
t – Double D
evelopme
nt
Roller Proce
ss
The dev
elopment units
operate in th
e following
order: K
→
M
→
C
→
Y
B051D351.
W
MF
1
2
4
5
6
7
8
9
3
305
