OVERVIEW 26 July 2002
6-8
Development Units
1. Rear development board
2. Laser synch. detection board
3. Front development board
4. Polygonal mirror motor
5. LD unit
6. Memory chip M
7. Memory chip C
8. Memory chip Y
9. Memory chip K
B051D102.WMF
1
2
3
4
6
5
7
8
9
