Ricoh U-C1 B051 - Table 1: Tray 1 and 2 Paper Size

26 July 2002 DUMMY
5-67
Service
Tables
Table 1: Tray 1 and 2 Paper Size
Switch North America Europe/Asia Value
1000 81/2" x 11" SEF 81/2" x 11" SEF 00001110
1001 B5 SEF B5 SEF 00000110
1010 51/2" x 81/2" LEF A5 LEF 00001010
1011 11" x 17" SEF A3 SEF 00000010
1100 A4 SEF A4 SEF 00001100
1101 B5 LEF B5 LEF 00000100
1110 81/2" x 11" LEF A4 LEF 00001000
1111 81/2" x 14" SEF B4 SEF 00000000
0: pushed
1: not pushed
Table 2: By-pass Tray Paper Size
Paper Width Value Paper Width Value
A3/11"/12"
01110000 B5/8" 10010000
B4 00110000 A5/5.5" 11010000
A4/8.5" 10110000 B6 11000000
Table 3: Optional Paper Tray Unit Paper Size
Size North America Europe/Asia Code
A3 SEF Detected Detected 10000100
B4 SEF None Detected 10001101
A4 SEF None Detected 10000101
A4 LEF Detected Detected 00000101
B5 LEF Detected Detected 00001110
A5 LEF None Detected 00000110
DLT SEF Detected Detected 10100000
LG SEF Detected None 10001101
LT SEF Detected None 10000101
LT LEF Detected Detected 00100110
HLT LEF Detected None 00000110
Table 4: Optional Paper Tray Unit Paper Near End
Remaining paper Paper height sensor 2 Paper height sensor 1 Code
Full ON ON 11111111
Nearly full OFF ON 11111110
On OFF 11111101
Near end OFF OFF 11111100
