Ricoh U-C1 B051 - Page 241

DUMMY 26 July 2002
5-66
Reading
SP5-803
-XXX
Description
0 1
71
Bank Cover 1
Right cover (vertical guide
switch)
Closed Open
72
Bank Cover 2
2nd optional tray: Right
cover (vertical guide
switch)
Closed Open
73 Bank Tray 1 Set 1st optional tray: Set Not set Set
74 Bank Tray 2 Set 2nd optional tray: Set Not set Set
75
Bank Tray 1 Paper
End
1st optional tray: Paper
end
Not end End
76
Bank Tray 2 Paper
End
2nd optional tray: Paper
end
Not end End
77
Bank Tray 1 Paper
Size
1st optional tray: Paper
size
78
Bank Tray 2 Paper
Size
2nd optional tray: Paper
size
(See table 2.)
79
Bank Tray 1 Paper
Height
1st optional tray: Paper
height
80
Bank Tray 2 Paper
Height
2nd optional tray: Paper
height
(See table 3.)
81 Duplex Entrance Duplex: Entrance sensor Not detected Detected
82 Duplex Exit Duplex: Exit sensor Detected Not detected
83 Duplex Open Duplex unit open switch Closed Open
84 Duplex Cover Duplex cover sensor Open Closed
86
Scanner Home
Position
Scanner HP sensor
Detected Not detected
87 Recycle Counter Mechanical Counter Set Set Not set
88 Counter Set Set Not set
89 Key Counter Set Set Not set
90
Shift Tray Home
Position Sensor
Detected Not detected
91
Platen Cover
Sensor
Detected Not detected
