Ricoh U-C1 B051 - Page 240

26 July 2002 DUMMY
5-65
Service
Tables
Reading
SP5-803
-XXX
Description
0 1
25
Discharge Bias
Leak
30 Toner End: M Toner end sensor: M Not end End
31 Toner End: C Toner end sensor: C Not end End
32 Toner End: Y Toner end sensor: Y Not end End
33 Toner End: K Toner end sensor: K Not end End
34
Toner Unit: M
Toner cartridge memory
chip: M
Not set Set
35
Toner Unit: C
Toner cartridge memory
chip: C
Not set Set
36
Toner Unit: Y
Toner cartridge memory
chip: Y
Not set Set
37
Toner Unit: K
Toner cartridge memory
chip: K
Not set Set
38
O/B Waste Toner
Sensor
OPC belt waste toner
sensor
Full Not full
39
O/B Waste Toner
Switch
OPC belt waste toner
bottle switch
Set Not set
40 Belt Mark Belt mark sensor Not detected Detected
41 New PCU Sensor Not used - -
42
T/B Waste Toner
Sensor
Transfer belt waste toner
sensor
Full Not full
43
T/B Waste Toner
Switch
Transfer belt waste toner
bottle switch
Set Not set
44 LD 5V Cover Interlock switch Closed Open
45 Left Cover Closed Open
46 Right Upper Cover Closed Open
47 Front Cover Closed Open
48
Development Motor
Lock
Development motor lock
Locked Not locked
49 Main Motor Lock Main motor lock Locked Not locked
50
Paper Feed Motor
Lock
Paper feed motor lock
Locked Not locked
51 Polygon Motor Lock Polygon motor lock Locked Not locked
52 1 Bin Set Set Not set
53 1 Bin Paper Sensor Detected Not detected
60 Duplex Connection Duplex unit Not connected Connected
61 Bank 1 Connection 1st optional paper tray Not connected Connected
62 Bank 2 Connection 2nd optional paper tray Not connected Connected
63
Finisher
Connection
Finisher Connection
Not connected Connected
64 Bridge Exit Detected Not detected
65 Bridge Relay Detected Not detected
66 Bridge Set Set Not set
67 Bridge Right Cover Closed Open
68 Bridge Left Cover Closed Open
69
Bank Upper Relay
Relay Sensor 3 (optional
paper tray unit)
No paper Paper present
70
Bank Lower Relay
Relay Sensor 4 (optional
paper tray unit)
No paper Paper present
