26 July 2002 INSTALLATION REQUIREMENTS
1-1
Installation
1. INSTALLATION
1.1 INSTALLATION REQUIREMENTS
1.1.1 ENVIRONMENT
1. Temperature Range:
10°C to 32°C (50°F to 89.6°F) (humidity to be 54% at
32°C, 89.6°F)
2. Humidity Range:
15% to 80% Rh (temperature to be 27°C, 80.6°F at
80%)
3. Ambient Illumination: Less than 1,500 lux (keep the machine out of direct
sunlight.)
4. Ventilation: Air turnover of more than 30 m
3
/hr/person or more
5. Ambient Dust: Less than 0.10 mg/m
3
(2.7 x 10
– 6
oz/yd
3
)
6. Avoid exposing the machine to sudden temperature changes, which include:
1) Direct cool air from an air conditioner
2) Direct heat from a heater
7. Avoid installing the machine in areas that may be exposed to corrosive gas.
8. Install the machine at a location lower than 2,000 m (6,500 ft.) above sea level.
9. Install the machine on a strong, level base.
10. Avoid installing the machine in areas that may be subjected to strong vibration.
1.1.2 MACHINE LEVEL
Front to back: Within 5 mm (0.2") of level
Right to left: Within 5 mm (0.2") of level
