26 July 2002 DIP SWITCHES
5-85
Service
Tables
Counter
In the User/Tools Counter display, touch Counter.
The following SP mode counters will be displayed.
• Copy Counter (SP5-914)
View the settings, touch Print Counter Exit to return to the User Tools/Counter
display, and then touch Exit to return to the copy window.
5.6 DIP SWITCHES
Controller Board: SW2
DIP SW No. OFF ON
1
Boot-up from machine Boot-up from IC card
2
3
4
Not used (keep at OFF)
If the controller firmware download attempt failed, you must boot the machine from
the IC card. To do this, set DIP SW 1 on the controller board to ON.
BICU Board: SW2
DIP
SW
No.
Function
OFF
ON
1 Machine
Type
U-C1b
U-C1a
2 Off: Off: Off: On: On: Off:
3 Destination Off: JAN On: NA Off: EU On: AA Off: TWN On: CHN
4 Off: Off: On: Off: Off: On:
5 Not used
6 Not used
Keep at OFF
JAN: Japan, NA: North America, EU: Europe, AA: Asia, TWN: Taiwan, CHN: China
