Finisher Input Check (SP6-117)
1. Enter the SP mode and select SP6-117.
2. Enter the number (1 – 113) for the item that you want to check. A small box will
be displayed on the SP mode screen with a series of 0’s and 1’s, as shown
below. However, only bit ) at the right side of the screen is valid.
0 0 0 0 0 0 0 0
Bit 7 6 5 4 3 2 1 0
3. Check the status of each item against the corresponding bit numbers listed in
the table below.
Reading
No. Description
0 1
1 Entrance Sensor Activated Deactivated
2 Tray Exit Sensor Activated Deactivated
4 Staple Entrance Sensor Activated Deactivated
5 Stapler Home Position Sensor Activated Deactivated
6 Jogger Fence Home Position Sensor Activated Deactivated
8 Feed-out Belt Home Position Sensor Activated Deactivated
9 Stapler Tray Paper Activated Deactivated
10 Stapler Rotation Home Position Activated Deactivated
11 Staple Sensor Activated Deactivated
14 Staple Sheet Sensor Activated Deactivated
17 Exit Plate Home Position Sensor Activated Deactivated
18 Tray Shift Home Position Sensor Activated Deactivated
21 Stack Height Sensor Activated Deactivated
23 Tray Lower Limit Sensor Activated Deactivated
101 500 Fin Entrance Sensor Activated Deactivated
102 500 Fin Exit Sensor Activated Deactivated
103 500 Fin Jogger Home Position Sensor Activated Deactivated
104 500 Fin Top Cover Sensor Closed Opened
105 500 Fin Height Sensor Activated Deactivated
106 500 Fin Lever Sensor Activated Deactivated
107 500 Fin Upper Limit Sensor Activated Deactivated
108 500 Fin Near Limit Sensor Activated Deactivated
109 500 Fin Staple Cover Sensor Closed Opened
110 500 Fin Stapler Home Position Sensor Activated Deactivated
111 500 Fin Staple End Sensor Activated Deactivated
112 500 Fin Staple Sensor Activated Deactivated
113 500 Fin Stapler Lock Sensor Locked Not Locked
