SERVICE PROGRAM MODE 26 July 2002
5-6
1
Mode No.
(Class 1, 2, and 3)
Function / [ Setting ]
13
Heating: Duplex/Full
Color
Sets the heating roller temperature for duplex printing
(both sides) in full-color mode.
[120 ~ 190 / 165 / 1°C/step]
14 Pressure: Idling
Sets the temperature at which the pressure roller starts
idling.
[30 ~ 100 / 10 / 1°C/step]
15 Pressure: Ready
Sets the temperature at which the pressure roller
becomes ready for printing.
[60 ~ 150 / 70 / 1°C/step]
16 Pressure: Standby
Sets the pressure roller temperature for the ready
(standby) condition. After the main switch has been
turned on, the machine enters this condition when the
pressure roller temperature reaches the temperature
specified in this SP mode. When the machine is
recovering from energy saver or auto off mode, the
machine becomes ready when both heat and pressure
roller temperatures reach the specified temperature.
Heating roller: SP1-105-3
[60 ~ 150 / 120 / 1°C/step]
27 Heating: OFFSET +
Sets the heating roller temperature correction for when
room temperature is 15°C or lower.
[0 ~ 20 / 5 / 1°C/step]
28 Pressure: OFFSET +
Sets the pressure roller temperature correction for when
room temperature is 15°C or lower.
[0 ~ 20 / 0 / 1°C/step]
29 Heat: OFFSET –
Sets the heating roller temperature correction for when
room temperature is 30°C or higher.
[0 ~ 20 / 5 / 1°C/step]
105*
30 Pressure: OFFSET –
Sets the pressure roller temperature correction for when
room temperature is 30°C or higher.
[0 ~ 20 / 0 / 1°C/step]
Temperature Display
1 Heating Roller
106
2 Pressure Roller
Displays the current temperature of the heating and
pressure rollers.
Fusing Nip
1 Execute Mode Checks the fusing nip width using an OHP sheet.
• The OHP sheet stops in the fusing unit for the
specified time (
☛
SP1-109-2).
• The nip width should be 9 ± 0.5 mm at front and rear.
If this requirement is not met, change the fusing unit.
109
2 Stop Duration
Adjusts the stoppage time for the OHP sheet in the
fusing unit (☛ SP1-109-1).
[0 ~ 100 / 10 / 1 s/step]
Exit Full Timer 920
1 Exit Full Timer
[10 ~ 60 / 10 / 1 s/step] DFU
Fusing Oil Add 930
1 Fusing oil add
Forces the oil pump to supply silicone oil up from the oil
tank to the tank in the oil supply unit. If the oil end
sensor detects oil in the oil supply unit, this SP will not
start the pump.
To Next Page
