26 July 2002 SERVICE PROGRAM MODE
5-9
Service
Tables
2
Mode No.
(Class 1, 2, and 3)
Function / [ Setting ]
8 4 Colors: 2nd color
[30 ∼ 140 / 130 / 10 µA/step]
The second color toner image of 4-color printing
9 3 Colors: 3rd color
[30 ∼ 140 / 130 / 10 µA/step]
The third color toner image of 3-color printing
10 4 Colors: 3rd color
[30 ∼ 140 / 130 / 10 µA/step]
The third color toner image of 4-color printing
11 4 Colors: 4th color
[30 ∼ 140 / 130 / 10 µA/step]
The fourth color toner image of 4-color printing
12 Print start
[30 ∼ 140 / 70 / 10 µA/step]
After the first color toner image
13 Print end
[30 ∼ 140 / 70 / 10 µA/step]
After the second color toner image
14 After 1st Color
[30 ∼ 140 / 70 / 10 µA/step]
After the third color toner image
15 After 2nd Color
[30 ∼ 140 / 70 / 10 µA/step]
After the final color toner image
16 After 3rd Color
[30 ∼ 140 / 70 / 10 µA/step]
Development start
17 After 4th Color
[30 ∼ 140 / 70 / 10 µA/step]
Development end
18 1 Color: Front: Idling
[30 ∼ 140 / 70 / 10 µA/step]
Waiting for thick paper or OHP before creating the front
side image for 1-color printing
19 1 Color: Rear: Idling
[30 ∼ 140 / 70 / 10 µA/step]
Waiting for thick paper or OHP before creating the rear
side image for 1-color duplex printing
20 2 Colors: Idling
[30 ∼ 140 / 70 / 10 µA/step]
Waiting for thick paper or OHP before creating an image
for 2-color printing
21 3 Colors: Idling
[30 ∼ 140 / 70 / 10 µA/step]
Waiting for thick paper or OHP before creating an image
for 3-color printing
22 4 Colors: Idling
[30 ∼ 140 / 70 / 10 µA/step]
Waiting for the thick paper or OHP before creating an
image for 4-color printing
301
23 Power On Recovery
[30 ∼ 140 / 70 / 10 µA/step]
Machine start and jam recovery
Transfer Belt Environment
1 Threshold 1 Adjusts the environmental threshold for the transfer belt.
[0 ~ 100.0 / 3.5 / 0.1 g/m
3
/step] DFU
303*
2 Threshold 2
[0 ~ 100.0 / 19.0 / 0.1 g/m
3
/step] DFU
Transfer Belt Environment
1 LL/Image/1 Color/1st
[50 ~ 200 / 85 / 1 %/step] DFU
2 LL/Image/1 Color/1st
[50 ~ 200 / 85 / 1 %/step] DFU
3 LL/Image/1 Color/1st
[50 ~ 200 / 100 / 1 %/step] DFU
4 LL/Image/1 Color/1st
[50 ~ 200 / 100 / 1 %/step] DFU
5 LL/Image/1 Color/1st
[50 ~ 200 / 100 / 1 %/step] DFU
6 LL/Image/1 Color/1st
[50 ~ 200 / 100 / 1 %/step] DFU
7 LL/Image/1 Color/1st
[50 ~ 200 / 100 / 1 %/step] DFU
304
8 LL/Image/1 Color/1st
[50 ~ 200 / 100 / 1 %/step] DFU
