SERVICE PROGRAM MODE 26 July 2002
5-16
2
Mode No.
(Class 1, 2, and 3)
Function / [ Setting ]
Cleaning Bias NN1
1 1 Color
Adjusts the transfer belt cleaning voltage when absolute
humidity AH (g/m
3
) is in the following range:
8.0 < AH ≤ 14 (this is the ‘NN1’ humidity range) DFU
[0 ~ 2000 / 1700 / 10 Volt/step]
2 2 Colors-4 Colors
[0 ~ 2000 / 1700 / 10 Volt/step]
3 Half Speed/1 Color
[0 ~ 2000 / 1700 / 10 Volt/step]
4
Half Speed/2 Colors-4
Colors
[0 ~ 2000 / 1700 / 10 Volt/step]
5 ID pattern
[0 ~ 2000 / 1600 / 10 Volt/step]
6 No Image Area
[0 ~ 2000 / 1400 / 10 Volt/step]
402*
7 Jam Recovery
[0 ~ 2000 / 1600 / 10 Volt/step]
Cleaning Bias NN2
1 1 Color
Adjusts the transfer belt cleaning voltage when absolute
humidity AH (g/m
3
) is in the following range:
14 < AH ≤ 19 (this is the ‘NN2’ humidity range) DFU
[0 ~ 2000 / 1700 / 10 Volt/step]
2 2 Colors-4 Colors
[0 ~ 2000 / 1700 / 10 Volt/step]
3 Half Speed/1 Color
[0 ~ 2000 / 1700 / 10 Volt/step]
4
Half Speed/2 Colors-4
Colors
[0 ~ 2000 / 1700 / 10 Volt/step]
5 ID pattern
[0 ~ 2000 / 1600 / 10 Volt/step]
6 No Image Area
[0 ~ 2000 / 1400 / 10 Volt/step]
403*
7 Jam Recovery
[0 ~ 2000 / 1600 / 10 Volt/step]
Cleaning Bias HH
1 1 Color
Adjusts the transfer belt cleaning voltage when absolute
humidity AH (g/m
3
) is in the following range:
19 < AH (this is the ‘HH’ humidity range) DFU
[0 ~ 2000 / 1700 / 10 Volt/step]
2 2 Colors-4 Colors
[0 ~ 2000 / 1700 / 10 Volt/step]
3 Half Speed/1 Color
[0 ~ 2000 / 1700 / 10 Volt/step]
4
Half Speed/2 Colors-4
Colors
[0 ~ 2000 / 1700 / 10 Volt/step]
5 ID pattern
[0 ~ 2000 / 1600 / 10 Volt/step]
6 No Image Area
[0 ~ 2000 / 1400 / 10 Volt/step]
404*
7 Jam Recovery
[0 ~ 2000 / 1600 / 10 Volt/step]
Fusing Bias
1 Normal/1 Color/1st
Adjusts the fusing bias voltage. DFU
[1000 ~ 4000 / 3000 / 100 Volt/step]
2 Normal/1 Color/2nd
[1000 ~ 4000 / 3000 / 100 Volt/step]
3 Normal/Full Color/1st
[1000 ~ 4000 / 2500 / 100 Volt/step]
4 Normal/Full Color/2nd
[1000 ~ 4000 / 2500 / 100 Volt/step]
5 Thick/1 Color/1st
[1000 ~ 4000 / 3000 / 100 Volt/step]
6 Thick/1 Color/2nd
[1000 ~ 4000 / 3000 / 100 Volt/step]
7 Thick/Full Color/1st
[1000 ~ 4000 / 2500 / 100 Volt/step]
500*
8 Thick/Full Color/2nd
[1000 ~ 4000 / 2500 / 100 Volt/step]
