26 July 2002 SERVICE PROGRAM MODE
5-27
Service
Tables
4
Mode No.
(Class 1, 2, and 3)
Function / [ Setting ]
19 B:M
20 B:Y
21 M:K
22 M:C
23 M:M
540
24 M:Y
Adjust the vector correction of the filter in the CCD on
the SBU unit.
[–128 ∼ 127 / 0 / 1 /step]
When replacing the SBU, input the data from the data
sheet that is included with the spare SBU unit.
Gain Adjustment: R
1 R EVEN
628
2 R ODD
Displays the values of the even and odd gain
adjustment.
Gain Adjustment: G
1 R EVEN
629
2 R ODD
Displays the values of the even and odd gain
adjustment.
Gain Adjustment: B
1 R EVEN
630
2 R ODD
Displays the values of the even and odd gain
adjustment.
Reference Adjustment: R 685
1
Reference Adjustment:
R
Adjusts the ADC reference voltage. Details are in
Replacement and Adjustment.
[0 ∼ 255 / 136 / 1 /step]
Reference Adjustment: G 686
1
Reference Adjustment:
G
Adjusts the ADC reference voltage.
[0 ∼ 255 / 136 / 1 /step]
Reference Adjustment: B 687
1
Reference Adjustment:
B
Adjusts the ADC reference voltage.
[0 ∼ 255 / 136 / 1 /step]
DF: Density Adjustment 688
1
DF: Density
Adjustment
Adjusts the brightness for scanning using the ARDF.
[83 ∼ 100 / 86 / 1 %/step]
The density when scanning from the DF exposure glass
tends to be higher than the density from the main
exposure glass. SP4-688 adjusts the density on the DF
exposure glass.
DF: Density Correction
1
DF: Density
Correction: R
Adjusts the red density when scanning with the ARDF
[–20 ∼ 20 / 0 / 1 %/step]
2
DF: Density
Correction: G
Adjusts the green density when scanning with the ARDF
[–20 ∼ 20 / 0 / 1 %/step]
800
3
DF: Density
Correction: B
Adjusts the blue density when scanning with the ARDF
[–20 ∼ 20 / 0 / 1 %/step]
ACC Data Display
1 R DATA 1
2 G DATA 1
3 B DATA 1
4 R DATA 2
5 G DATA 2
902
6 B DATA 2
Displays ACC data.
[0 ∼ 255 / 0 / 1 /step]
