26 July 2002 SERVICE PROGRAM MODE
5-55
Service
Tables
7
Mode No.
(Class 1, 2, and 3)
Function / [ Setting ]
13
Registration
(From Duplex)
14 Duplex Exit
15 Interchange Exit:: ON
16 Paper Exit: On
17 Bridge Exit: On
18 Bridge Relay: On
19 Duplex Entrance 1: On
20 Duplex Entrance 2: On
23 Duplex Exit: On
40 Finisher Entrance: On
41 Finisher Exit: On
58 1st Relay: Off
59 2nd Relay: Off
60 3rd Relay: Off
61 4th Relay: Off
63 Registration: Off
64 Fusing Exit
65 Interchange Exit: Off
66 Paper Exit: Off
67 Bridge Exit: Off
68 Bridge Relay: Off
69 Duplex Entrance 1: Off
70 Duplex Entrance 2: Off
73 Duplex Exit: Off
100 Finisher Entrance: Off
101 Finisher Exit: Off
103 Finisher Staple
104
Finisher Stack Feed-
out
105
Finisher Paper Taking
out
107 Finisher Drive Error
108 Finisher Tray Lift Error
109 Finisher Jogger Error
110
Finisher Tray Shift
Error
111 Finisher Stapler Error
112
Finisher Stack Feed-
out
114
Finisher Feed out
Error
504*
115 Finisher No Response
Original Tray by Location
5
Registration Sensor
(On Check)
6
Relay Sensor (On
Check)
Relay Sensor = Original Trailing Edge Sensor (S9)
505
7
Inverter Sensor (On
Check)
Inverter Sensor = Original Reverse
Sensor (S10)
