Ricoh U-C1 B051 - Page 236

26 July 2002 SERVICE PROGRAM MODE
5-61
Service
Tables
7
Mode No.
(Class 1, 2, and 3)
Function / [ Setting ]
14 Tray 2 Roller
15 Tray 3 Roller
16 Tray 4 Roller
17 By-pass Feed
18 Paper Transfer Unit
19 Toner: M
20 Toner: C
21 Toner: Y
22 Toner: Bk
907
23 ADF
[0 ~ 255 / 0 / 1 /step]
Process Control Counter 908
1
Process Control
Counter
Displays the process control counter.
[0 ~ 9999999 / 0 / 1 sheet/step]
Process Control Reset 909
1 Process Control Reset Resets the process control counter.
Oil Counter 913
1 Oil Counter Displays the oil supply unit counter.
[0 ~ 65535 / 0 / 1 sheet/step]
Oil Clean Counter Reset 914
1
Oil Clean Counter
Reset
Resets the oil cleaner counter.
Process Error Log
1 Log 1
2 Log 2
915
3 Log 3
Displays the latest three process control error logs.
The following are the error codes:
Development unit initial settings errors:
• 110: Incorrect image detected by cyan ID sensor
• 116: Incorrect image detected by magenta ID
sensor
• 118: No black image
Development bias settings errors:
• 113: Incorrect image detected by cyan ID sensor
• 114: Incorrect image detected by magenta ID
sensor
• 115: Incorrect image detected by yellow ID sensor
• 123: Incorrect image detected by black ID sensor
ID sensor errors:
• 103: ID sensor error
• 104: ID sensor unable to detect image
• 105: OPC belt not detected
Machine Counter 920
1 Machine Counter
[0 ~ 0xFFFFFFF / 0 / 1 /step]
Machine Counter Clear 921
1
Machine Counter
Clear
Clears the machine counter.
Toner End Counter
1 K Toner
2 C Toner
3 M Toner
922
4 Y Toner
Displays the toner end counter, which indicates the
possible print count after a toner near end.
