Monitoring BroadShield
You can use the BroadShield Web UI to monitor the jamming/spoofing status, or
the VersaSync Web UI. In the latter case, you will be informed of a Major Alarm,
as described below:
BroadShield Alarm
If BroadShield detects a jamming or spoofing event, VersaSync will emit a
BroadShield Critical, Major Alarm (see illustration below). VersaSync will go into
Holdover (yellow HOLD status light) and – depending on the BroadShield Ser-
vice setting (see "Enabling/Disabling the BroadShield Service" on page186) and
your VersaSync settings – will either remain in sync (green SYNC status light), i.e.
it will continue to output time and frequency signals considered valid, or it will go
out of sync (red SYNC light).
You can also configure a notification alarm, see "Enabling/Disabling the
BroadShield Service" on page186.
BroadShield Web UIMonitoring
The BroadShield Web UI will also display real time signal status information, or a
map status.
Note: If at any time you receive an error message Failed to connect
to the unit, the VersaSync Web UImay have timed out (see "Web UI
Timeout" on page249). Refresh your browser page to log back in.
To open the BroadShield user interface:
1. Navigate to TOOLS: SYSTEM > Broadshield.
2. The embedded Broadshield Web UI will open, displaying the Dashboard
and providing access to the following panels:
DASHBOARD
The Dashboard panel displays up to 7 days of history data, and a real-time amp-
litude frequency spectrum. The headline background color indicates the current
jamming/spoofing status: red= jamming or spoofing detected; green = no alarms
at this time
