SATO CL4NX Plus User Manual

15
Print head
• When opening and closing the print head, make sure that objects
other than media do not get caught. Otherwise, it could result in injury
or damage.
Cover
• When opening and closing the cover, be careful not to get your
fingers trapped in between. Also, firmly hold the cover to prevent it
from closing unexpectedly.
Always keep the cover
of the product closed
• Always have the cover of the product closed when using. You could
get injured by touching the moving parts. Also, dust or foreign objects
could get inside, possibly resulting in the product to malfunction.
When not using the
product for a long time
• When not using the product for a long time, unplug the power cord
from the outlet to maintain safety.
During maintenance
and cleaning
• When maintaining and cleaning the product, unplug the power cord
from the outlet to maintain safety.

SATO CL4NX Plus Specifications

General

Display type	LCD
Product color	Black
Built-in display	Yes
Display diagonal	3.5 \
Type	POS printer
Color	No
Print speed	14 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	305 x 305 DPI
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Maximum media length	600 mm
Maximum roll diameter	254 mm
Supported paper width	39.5 - 128 mm
Maximum printing width	128 mm
Printing media thickness	0.06 - 0.268 µm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Wi-Fi	-
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0+HS
Standard interfaces	Bluetooth, Ethernet, RS-232C, Serial, USB 2.0
Serial interface type	RS-232C
USB 2.0 ports quantity	3
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	271 mm
Width	457 mm
Height	321 mm
Weight	15100 g
