SATO CL4NX Plus - Page 465

465
Resolution CL4NX Plus
(1 dot = 0.042 mm (0.0017"))
When you decrease the setting value, the print position moves in the feed direction (toward the
front part of the media).
When you increase the setting value, the print position moves opposite the feed direction (toward
the end part of the media).
Offset
Set the stop position of the media.
The setting range varies depending on the print resolution of the product.
The setting range is as follows:
Resolution CL4NX Plus
203dpi
(1 dot = 0.125 mm (0.0049"))
-30 to 0 to 30 dots
305dpi
(1 dot = 0.083 mm (0.0033"))
-45 to 0 to 45 dots
609dpi
(1 dot = 0.042 mm (0.0017"))
-90 to 0 to 90 dots
When you decrease the setting value, the stop position moves in the feed direction (toward the
front part of the media).
When you increase the setting value, the stop position moves opposite the feed direction (toward
the end part of the media).
Darkness Adjust
Fine tune the print darkness of the test print.
0 is the lightest and 99 is the darkest.
• The value of [Pitch], [Offset] and [Darkness Adjust] set in the [Factory] menu will be
reflected to the same item settings in the [Configure List] menu, [Configure QR] menu,
[Paper Sensor] menu and [Head Check] menu.
