469
Resolution CL4NX Plus
(1 dot = 0.042 mm (0.0017"))
Pitch
Set the print position in the vertical direction.
The setting range varies depending on the print resolution of the product.
The setting range is as follows:
Resolution CL4NX Plus
203 dpi
(1 dot = 0.125 mm (0.0049"))
-30 to 0 to 30 dots
305 dpi
(1 dot = 0.083 mm (0.0033"))
-45 to 0 to 45 dots
609 dpi
(1 dot = 0.042 mm (0.0017"))
-90 to 0 to 90 dots
When you decrease the setting value, the print position moves in the feed direction (toward the
front part of the media).
When you increase the setting value, the print position moves opposite the feed direction (toward
the end part of the media).
Offset
Set the stop position of the media.
The setting range varies depending on the print resolution of the product.
The setting range is as follows:
Resolution CL4NX Plus
203 dpi
(1 dot = 0.125 mm (0.0049"))
-30 to 0 to 30 dots
305 dpi
(1 dot = 0.083 mm (0.0033"))
-45 to 0 to 45 dots
609 dpi
(1 dot = 0.042 mm (0.0017"))
-90 to 0 to 90 dots
When you decrease the setting value, the stop position moves in the feed direction (toward the
front part of the media).
When you increase the setting value, the stop position moves opposite the feed direction (toward
the end part of the media).
