623
Item Specification
◦ 203 dpi: 54 to 2497 mm (2.13" to 98.30") (with liner: 57 to 2500 mm
(2.24" to 98.42"))
◦ 305 dpi: 54 to 1497 mm (2.13" to 58.94") (with liner: 57 to 1500 mm
(2.24" to 59.05"))
◦ 609 dpi: 54 to 397 mm (2.13" to 15.63") (with liner: 57 to 400 mm
(2.24" to 15.75"))
Linerless mode
◦ 38 to 120 mm (1.50" to 4.72")
Usable Media Types Same as the product specifications. If the label color is silver or
laminated, however, it makes it difficult for the barcode checker to read
the barcode, as the light of the barcode checker may cause a reflection
on the label surface. Be sure to do a test read carefully in advance.
1D
Barcode
Checker
(1) Media feed direction
Readable
Barcode
Orientations
2D
Code
Checker
(1) Media feed direction
Place the barcode within the size of the visual field. Do a test read
carefully in advance.
To Next Page
