External Signal (EXT) Interface
756
Pin
No.
I/O Description Electric Conditions
(Voltage, Current (Max))
9 Output
Offline
Outputs a low signal when the product is in
Offline mode.
Withstand voltage 50 V
Sink current 50 mA
10 Output
Ribbon Near End
Outputs a high signal when the ribbon near
end is detected.
Withstand voltage 50 V
Sink current 50 mA
11 - - -
12 - +24 V ± 10% 2 A
13 - Vcc +5 V 500 mA
14 - - -
* Output
Wait signal for dispense completion
Outputs a low signal when the dispense is
completed.
You can set the pin number for output
through the [Settings] > [Interface] >
[External I/O] > [Signals] > [Outputs] menu.
Withstand voltage 50 V
Sink current 50 mA
* Output
Label Near End signal
Outputs a high signal when the label near
end is detected.
You can set the pin number for output
through the [Settings] > [Interface] >
[External I/O] > [Signals] > [Outputs] menu.
Withstand voltage 50 V
Sink current 50 mA
• You can set the external signal (EXT) type (TYPE1 to TYPE4) for Print Done output
signal of pin No. 6. Refer to the [EXT Mode] screen of the [Settings] > [Interface] >
[External I/O] > [Signals] menu for details.
• You can set the pin number for input and output through the [Settings] > [Interface] >
[External I/O] > [Signals] > [Inputs] and [Outputs] menu.
• The Print Done signal of pin No. 6 is not outputted when 0 is specified in the number of
cuts in the command specifying the number of cuts during the cutter operation.
