Sirona Sinius - Page 227

63 22 726 D3561
D3561.201.01.03.02 05.2012
227
Sirona Dental Systems GmbH 10 Overview of all function keys
Operating Instructions SINIUS / SINIUS CS 10.2 Start program
båÖäáëÜ
10.1.2 Assistant element
Assistan t element
Tumbler filling
on/off
Flushing of the cuspidor bowl
on/off
Operating light/Composite function
Switches the operating light on/off.
Switches the composite setting for the operating light on/off.
Reduced light intensity< 8,000 lux
Chair program S
Mouth rinsing position with last-position memory function
(programmable)
Chair program 0
Entry/exit position (programmable)
Freely selectable function
The
Hash key on the assistant element can be configured in the Setup
program. The key allows the user to switch the X-ray viewer or the white
screen function on the SIVISION monitor on or off or alternatively to
activate the bell or hash relay.
Freely available relay 230 VAC, 6 A
(connected by the service engineer).
10.2
Start program
Start program
Chair program S
Mouth rinsing position with memory function (programmable)
Chair program 0
Entry/exit position (programmable)
Chair programs 1 and 2
(programmable)
Moving the headrest in/out
if a motor-driven headrest is installed
Inclining the headrest
if a motor-driven headrest is installed
Tilting the patient couch
Compensated motion of the seat and backrest without any compression
or stretching effects for the patient
Adjusting the chair height
