AUTOMATIC TRANSAXLE (M13 ENGINE) 7B1-123
Disassembly
1) Remove torque converter (1).
2) Remove engine mounting LH bracket (1).
3) Remove manual select lever (1).
4) Uncaulk lock washer (1), then remove lock nut (2) and lock
washer (1).
CAUTION:
Remove torque converter as much straight as possible.
Leaning it may cause to damage oil seal lip.
1
1
2
