Smart Camera / Vision-Sensor / 1D-/2D-Code-Scanner / OCR Reader
11.7.3. Configuration
As a standard feature, the threshold module includes the following configuration options:
• Output Image.
11.7.3.1. Output Image
Objective
The threshold module’s output image can be linked as an input image in the following
modules.
Property
The following settings/results appear in the filter module’s output image:
Image Type Display of the image type
X (px)
Coordinate of the sensor image coordinate system (see section 18.3)
Y (px)
Width (px) Image width
Height (px) Image height
The following settings/results are displayed under binary:
Size Number of pixels in the image
Bit per Pixel Display of the number of bits required to transmit one pixel
Channel Type The binary channel type is displayed.
