11.9.3.1. Cluster List
Objective
Detected clusters are listed in this sub-module in order to subsequently transmit their
position, number of pixels etc. via an output.
Prerequisites
The following settings/results are displayed for any selected cluster:
Pixel-Size The number of pixels in the cluster is displayed.
A matchbox is placed around the detected cluster. The matchbox’s settings/results
can be displayed.
Width (px) Matchbox width
Height (px) Matchbox height
The following settings/results are displayed for the matchbox under origin:
X (px)
Coordinate of the sensor image coordinate system (see sec-
tion 18.3)
Y (px)
The following settings/results are displayed under pixel size:
Pixel-Size The number of pixels in the cluster is displayed.
The coordinates of the cluster’s center of gravity are displayed under center of gravity:
X (px)
Coordinate of the sensor image coordinate system (see sec-
tion 18.3)
Y (px)
11.10. Module Measure
11.10.1. Overview
Objective
Specify and perform dimensional conformance inspections of distances, lengths, di-
ameters or angles. Lines and circles are found with the help of search rays. Distances
and angles can be measured between detected lines or points.
Image Area
1. Sensor is correctly connected (see section 5.5)
2. Connection has been established from the sensor to the software (see section
10.1.1)
3. The camera is configured / images are selected (see section 11.2)
4. If applicable, tracking is configured (see sections 11.3 and 11.4)
Abbreviated Pro-
cedure
Specify dimensional inspection of position, distance, length, diameter or angle and
perform measurement.
To Next Page
