Smart Camera / Vision-Sensor / 1D-/2D-Code-Scanner / OCR Reader
11.24. Device Communication
11.24.1. Overview
Objective
Sensor communication dictates how data can be transmitted to the sensor, and how
the sensor itself transmits data.
Prerequisites
1. Sensor is correctly connected (see section 5.5)
2. Connection has been established from the sensor to the software (see section
10.1.1)
Procedure
Various communication options can be selected and the respective settings can be
adapted. UDP or RS-232 can be selected in addition to Profinet, FTP server and client.
11.24.2. Settings
Property
The following settings/results appear.
Process Time [ms] Sensor processing time for the module
Module State Error codes to give support in error diagnosis (see section
18.5)
11.24.3. Configuration
The communication module includes the following configuration options:
• Industrial Ethernet
• UDP
• RS-232
• FTP or SD Card
