Software Module
11.10.2.4. Measure Intersection
Objective
The angle between two lines is measured.
Procedure
First of all, activate the function in the toolbox.
Click the first line, and then the second.
Property
The following settings/results appear.
Output Angle
(degrees)
The angle between the two lines is displayed. A line is defined by
a starting point and an end point. The detected angle corresponds
to the angle of intersection of the two lines in the direction towards
their starting points. The value can be furnished with any desired
upper and lower thresholds. Click the ascertained value to this
end, and then click the button. Enter the desired upper and lower
threshold values to the window which then appears.
The coordinates of the detected intersection are displayed under output intersection
point:
X (px)
Coordinate of the sensor image coordinate system (see sec-
tion 18.3)
Y (px)
