10.1.3. Demo Projects
After clicking demo projects, a ready-made demo project can be opened. Differentiation is made between
training demos and application demos.
Training Demos
Training Demos
Training demos show sample settings for a software module. The module’s
mode of operation is made plainly apparent by means of the included image
sequence with fictitious objects. A tutorial is available for each training demo
on our microsite (www.wenglor.com/weQube), as well as on the included CD,
which shows how the demo project was created step by step.
Overview of available training demos and associated tutorials:
Training Demo Associated Tutorial
Training demo – Localizer Tutorial 4 – How to localize an object
Training demo – Region Tutorial 5 – How to set a region of interest
Training demo – Threshold Tutorial 6 – How to create a binary image in module
threshold
Training demo – Cluster Tutorial 7 – How to count clusters
Training demo – Threshold HSV Tutorial 8 – How to use the HSV threshold module for
colored images
Training demo – Filter Tutorial 9 – How to filter an image
Training demo – Measure Tutorial 10 – How to measure an object
Training demo – Reference image
comparison
Tutorial 11 – How to compare an image to a reference
Training demo – 1D barcode Tutorial 12 – How to read 1D barcodes
Training demo – 2D code Tutorial 13 – How to read 2D codes
Training demo – Match code Tutorial 14 – How to match a code with a string
Training demo – Coordinate Sys-
tem
Tutorial 15 – How to track an object independently of its
position and orientation
Training demo – Math, logic and
numeric comparison
Tutorial 16 – How to do numeric, mathematic or logic
operations with output values
Training demo – Digital Inputs
Outputs
Tutorial 17 – How to configure weQube's input and out-
put pins
Training demo – Communication
FTP
Tutorial 18 – How to set up weQube's communication
with FTP
Training demo – Communication
RS-232
Tutorial 19 – How to set up weQube's communication
with RS-232
Training demo – Communication
UDP
Tutorial 20 – How to set up weQube's communication
with UDP
Training demo – Communication
Profinet
Tutorial 21 – How to set up weQube's communication
with Profinet
Training demo – Statistics Tutorial 22 – How to analyze values statistically
Training demo – Graphic display Tutorial 23 – How to set up weQube's display
Training demo – Signal LEDs Tutorial 24 – How to set up weQube's signal LEDs
The training demos can be edited in order to test available setting options.
