11.21. Device IO Unit
11.21.1. Overview
Objective
The inputs and outputs can be configured in order to specify which action will take
place as the result of a given event.
Prerequisites
1. Sensor is correctly connected (see section 5.5)
2. Connection has been established from the sensor to the software (see section
10.1.1)
3. The camera is configured / images are selected (see section 11.2)
Procedure
Any desired results can be assigned to an output.
Any desired inputs can be configured as well.
11.21.2. Settings
Property
The following settings/results appear.
Process Time [ms] Sensor processing time for the module
Module State Error codes to give support in error diagnosis (see section
18.5)
Error Handling This setting can be used to set performance of the properties
when a linked event demonstrates an error status.
11.21.3. Configuration
The I/O unit module includes the following configuration options:
• IO Timings
• Digital IO 1
• Digital IO 2
• Digital IO 3
• Digital IO 4
• Digital IO 5
• Digital IO 6
