67
Smart Camera / Vision-Sensor / 1D-/2D-Code-Scanner / OCR Reader
Refreshing performance can also be influenced, i.e. whether or not camera images and parameters are cycli-
cally taken from the sensor (run mode), or if the refresh process is suspended (edit mode). The camera image
is refreshed cyclically in the run mode. No parameter changes are possible in this mode. You can switch back
and forth between the two modes by simultaneously pressing the space key and the run mode / edit mode
button.
Parameters can be changed in the edit mode, during which refreshing of the camera image is interrupted –
camera images are not cyclically loaded from the sensor as is the case with the run mode. Each time a param-
eter is changed, the current camera image is loaded from the sensor.
11. Software Module
11.1. Application Module
11.1.1. Overview
Objective
The uppermost level offers an overview of the project’s basic characteristics.
11.1.2. Setting Parameters
Characteris-
tics
The following settings/results are displayed:
Processing Time [ms] Sensor processing time for the entire project
Module Status Error codes for troubleshooting support (see section 18.6).
Processing Time, Last
Run [ms]
Total processing time for the last project run is displayed.
Module Status, Last
Run
The module status for the last run is displayed.
Run Counter The number of completed evaluations since the last time power
was switched on is displayed.
Available Memory [kB] Currently available capacity of the sensor’s flash memory is
displayed.
Filename The filename of the currently running project is displayed.
Project Version The version of the project is displayed. The version depends on
the version of the sensor firmware with which the project was
created.
Toggle Bit The value of this bit changes for each run from 0 to 1 and vice
versa.
Author The author of the project can be specified.
Info An additional information text can be entered for a more accu-
rate project description.
