11.5.3. Configuration
The region module includes the following configuration options:
• Region.
• Set.
Other shapes which are added also appear in addition to the standard shape (rectangle) under “Set”.
11.5.3.1. Region
Objective
The selected region of interest can be examined.
Image Area
The output region, which can be linked as an input region in the following modules,
appears white.
Property
The following settings/results for the module’s input image appear under “Image”:
Image Type Display of the image type
X (px)
Coordinate of the sensor image coordinate system (see section
18.3)
Y (px)
Width (px) Image width
Height (px) Image height
The following settings/results are displayed under mask for the input image.
Size Number of pixels in the input image
Bits per Pixel Display of the number of bits required to transmit one pixel
Channel Type The mask channel type is displayed.
The bounding box is positioned such that it encloses the entire specified region. The
following settings/results are displayed:
Width (px) Width of the bounding box
Height (px) Height of the bounding box
The following settings/results are displayed for the bounding box under origin:
X (px)
Coordinate of the sensor image coordinate system (see section
18.3)
Y (px)
