Software Module
11.3.2. Settings
Image Area
The coordinate system, which can be aligned to a taught in feature, is displayed. The
X-axis appears red, the Y-axis green.
Settings/Results
The following settings/results appear.
Process Time Sensor processing time for the process steps in the localizer
module
Module State Error codes to give support in error diagnosis. (see section
18.5)
Smallest
Difference
The difference in the number of pixels between the previously
taught in teach image and the currently found teach image is
read out. The results provide an indication of the probability
that the currently found reference is the correct reference.
Teach Reference
Auto
A possible position (area with highest contrast) is automatical-
ly detected for the teach box within the specified search box.
The coordinate system for tracking is aligned to this taught in
box. The results may serve as a good starting value. In case
the found position is not unique you should specify the refer-
ence position manually. The setting can also be changed ex-
ternally by means of linking to another value or event.
Teach Reference The reference specified in the teach box for the teach window
can be taught in and is then used as a reference value for all
other images. The setting can also be changed externally by
means of linking to another value or event.
The coordinate system for tracking is aligned to this taught
in box.
Note: The area to be taught in must be positioned at a
location with as much contrast as possible in the teach box
sub-module before the teaching process.
Input Image Selection of the channel for the image input
