Software Module
Function Field
Stored images can be loaded to projects without any connection to the sensor.
Load stored images to the software. The image container appears. Sever-
al images can be selected at once by pressing and holding the CTRL key.
Note: Image sizes of up to 736 x 480 pixels can be loaded to the software.
11.2.2.1.White Balancing
Activating White Balancing
Procedure:
The view is changed to the module’s input image when the “White Balancing” tool is activated. After clicking
the place in the image which should be defined as “white” in the application, the algorithm ascertains the image
coordinates, from which it calculates the new “white value”. The algorithm calculates the new values for the
image’s red and blue content. The image is then redisplayed with the changed values.
Note: The white balancing function is only available with color versions of the weQube.
11.2.3. Configuration
The device camera module includes the following configuration options:
• Image Sensor
• Readout Box
• Auto Focus Box
