Smart Camera / Vision-Sensor / 1D-/2D-Code-Scanner / OCR Reader
4.2. List of Technical Data
Optical Characteristics
Working range ≥ 20 mm (weQube with auto-focus)
Resolution 736 px × 480 px
Field of vision See “Range of Vision Table”
Image chip See section 4.1 on available sensor types
Type of light See section 4.1 on available sensor types
Refresh rate (monochrome) ≤ 25 Hz
Refresh rate (color) ≤ 15 Hz
Service life 100,000 hours
Risk group (EN 62471) Free group
Electrical Characteristics
Supply power * 18 to 30 V DC
Current consumption (operating voltage = 24 V) < 200 mA
Response time (monochrome) < 40 ms
Response time (color) < 66 ms
Temperature range –25…55 °C **
Number of digital I/Os 6
Switching output voltage drop < 2.5 V
Switching output switching current 100 mA
Short-circuit proof Yes
Protected against polarity reversal Yes
Overload-proof Yes
Protection class III
Interfaces
Ethernet 10/100 Base TX; Ethernet or Profinet (see section 4.1 on avail-
able sensor types)
Mechanical Characteristics
Configuration interface Ethernet port
Housing material Aluminum
Protection IP67
Connector type M12×1, 12-pin
Ethernet connector type M12×1, 8-pin
Configurable as PNP, NPN or push-pull Yes
Can be switched to NC or NO operation Yes
Illumination output Yes
RS-232 interface Yes
General Data
Webserver
Yes (all Ethernet and Industrial Ethernet Devices, see section
“4.1. Available weQube Sensor Types”)
* Supply voltage residual ripple may not exceed 10 % (within the specified voltage range).
** –25 °C: Ambient conditions should not result in condensation; avoid the formation of ice on the front panel!
55 °C: Continuous illumination at max. 1 % or flash mode at 100 % brightness with an exposure time of ≤ 5 ms: may affect the service life of the
product.
