Shapes can also be edited in the settings/results field. Depending on the respective
shape, a specific selection of the parameters included in the following overall list can
be changed.
X-coordinate
Coordinate of the sensor image coordinate system (see section
18.3)
Y-coordinate
Width Width of the shape along the X-axis
Height Height of the shape along the Y-axis
Phi Rotation of the shape in degrees
Set operation A mathematical operation can be selected.
Add
The shape is added to the overall shape..
Subtract
The shape is removed from the overall
shaped.
Subtract Symmetric
The common area of the new shape is
removed from the overall shape.
Note: The area which is enclosed by the
new shape only is added to the overall
shape.
Intersect
Only the common area shared by the re-
spective shape and the overall shape is
selected as the region of interest.
Diameter Diameter of a circle
11.6. Module Filter
11.6.1. Overview
Objective
Filters are used to highlight desired image characteristics and to suppress undesired
image characteristics.
Prerequisites
1. Sensor is correctly connected (see section 5.5)
2. Connection has been established from the sensor to the software (see section
10.1.1)
3. The camera is configured / images are selected (see section 11.2)
4. If applicable, tracking is configured (see sections 11.3 and 11.4)
5. Region of interest is specified (see section 11.5)
Procedure
The desired type of filter can be selected and applied to the desired region.
To Next Page
