11.8.3. Configuration
The HSV threshold module includes the following configuration options:
• Output Image
• Hue
• Value
• Saturation
11.8.3.1. Output Image
Objective
The HSV threshold module’s output image can be linked as an input image in the fol-
lowing modules.
Property
The following settings/results appear in the HSV threshold module’s output image:
Image Type Display of the image type
X (px)
Coordinate of the sensor image coordinate system (see section 18.3)
Y (px)
Width (px) Image width
Height (px) Image height
The following settings/results are displayed under binary:
Size Number of pixels in the image
Bit per Pixel Display of the number of bits required to transmit one pixel
Channel Type The binary channel type is displayed.
11.8.3.2. Hue
Objective
The hue filter can be adjusted.
Property
The following settings/results appear.
Active The hue filter can be activated or deactivated.
Threshold Low Sets the lower threshold for hue.
Threshold High Sets the upper threshold for hue.
