11.16.3.3.Taught-In Rectangle
Objective
The region which encompasses the object or the distinctive element is displayed and
defined here.
Characteristics
Teach region settings are also displayed in the settings/results area.
Width (px) Teach region width
Height (px) Teach region height
The following settings are displayed under reference point.
X (px) Coordinates of the image sensor’s coordinate system
(see section 18.3)
Y (px)
