Smart Camera / Vision-Sensor / 1D-/2D-Code-Scanner / OCR Reader
11.24.3.2. Industrial Ethernet
Objective
The Industrial Ethernet interface can be configured.
Property
Process-Time [ms] Sensor processing time for the process steps
Module State Error codes to give support in error diagnosis (see section
“18.5. weQube Software Module States” on page 198)
Interface Type Note concerning Profinet: Depending on the type of sensor, the
corresponding interface type must be selected here.
Slot Count The same slot which is used in the controller must be entered
here.
Six Slots are available
Slot 1 Set to project change as a default value.
In order to be able to select a given project via the Profinet in-
terface, the project name on the sensor’s micro SD card must
be saved using the following format: “xx_testproject” (x: any
whole number from 0 to 9). Example: 01_testproject. Up to
254 projects can be addressed via the Profinet interface.
Note: Slot 1 cannot be changed manually. In order to change
a project via the Profinet interface, you only need to enter the
settings to the controller – the communication module is un-
necessary to this end.
Slot 2 Set to Profinet state as a default value. A list of possible
states can be found in the appendix in section “18.2. weQube
status information” on page 194.
Note: Slot 2 cannot be changed manually.
Slot 3-6 Freely configurable
Process Time [ms]
Sensor processing time for the process
steps
Module State
Error codes for troubleshooting support
(see section 18.6)
Slot Number
Corresponds to the controller’s slot
number
Module ID
Number specified by the DDBF
Submodule ID
Number specified by the DDBF
Data Size
Volume of data which is transmitted or
received
Direction
Specifies the direction of data transmis-
sion PL c to device or device to PL c
Data Nodes
Number of data packets
