Functions Description, OLED Display
6.8.2. Ethernet
Ethernet
Settings for the Ethernet connection
DHCP
IP address
Subnet mask
Std. gateway
MAC address
TCP/IP port
Network reset
 Back
 Run
DHCP: Display: DHCP on or DHCP off
IP address: Display of the selected IP address
Subnet mask: Display of the selected subnet mask
Std. gateway: Display of the selected standard gateway
MAC address: Display of the preselected, non-changeable MAC address
TCP/IP port: Display of the TCP/IP port
Network reset: Resets network settings to their default values
Changes do not become effective until after the sensor has been restarted.
6.8.2.1. DHCP
DHCP
DHCP server selection
O Off
O On
 Back
 Run
It’s possible to activate or deactivate assignment of the network configuration to the
sensor via a server.
6.8.2.2. IP Address
IP address
Setting the IP address
192168100001
+
The IP address can be set by pressing the “+” and “–” keys.
8
−
IP address
Checking the IP address for correctness
192.168.100.001
Entry correct?
Y
Correctness of the entered IP address is confirmed by pressing the “Y” key and the
address is transferred to the sensor.
If necessary, the IP address can be reentered after pressing the “N” key.
After pressing the t key, the display is returned to the Ethernet network menu with-
out saving the entered IP address.
N

The procedure for changing the subnet mask, the standard gateway and the TCP/IP port is analogous to enter-
ing the IP address.
